Référence : XTC-12M-GSI
GSM surveillance camera video wireless
Video surveillance camera GSM wireless for professionals and individuals. XTC-12M camera-phone is awesome with its compact system integrates an HD camera, a GSM module and a system of video recording and photo on SDHC card. The CMOS sensor HD camera is 12 megapixels, it provides images with a resolution maxiamal HQ 4000 × 3000 pixels and a resolution of 640 X 480 Videos at 20 frames per second. The recording system records video and photos on SDHC card up to 32 GB built-in GSM module in the rack stack can send picture MMS, real-time detection or by request or program.
Waterproof IR Camera and Flash
Near the sensor is invisible infrared LEDs, allowing detection at a place without light light (flash) 1 / 4 seconds. The increased maximum LED beacons are infrouges 10 meters.
A light sensor will automatically switch day / night mode.
The unit is waterproof with an SPF of 54 is protected against dust and protected against splashing water. Its temperature is extreme ranging from -30 ° C to 70 ° C.
Motion sensor for detecting an even more accurate
By the motion sensor PIR (pyroelectric infrared sensor) detects each abrupt change of heat and movement. Three sensors on the camera can detect 100 ° of viewing angle and up to 20 meters.
Time déclenchment sensor will be accelerated up to 1.2 seconds to capture a photo.
MMS sent directly to your phone in case of detection
The GSM module built into the camera allows you to receive MMS from January to March photo detection on phones registered. The SIM card (not supplied) may be the phone company of your choice and type of packages or prepaid card.
For France: Bouygues Telecom Orange or telephone are the only compatible for Switzerland: Sunrise or Orange and Orange Belgium. Sending MMS may ask the camera and set records for daily.
Long battery autonomy
Inside the unit introduced the necessary batteries and its rack extra battery for autonomy up to 6 months in standby mode. (8 AA batteries type LR06 not included).
In case of low battery SMS will be sent to alert you and replace the batteries.
A solar charger with internal battery 1500 mAH gives you a range of up to 1 year in duration standby. (Without detection)
Screen 2.4 "encrypted & Memory
Despite its small size the camera measures 115 x 57 x 30 mm behind the camera, a color screen 2.4 "inches, you can view your recordings, fit the sensor and to configure the device.
The device configuration is quick and easy. For added security, you can access your data with a password that encrypts your files.
You can upload photos of our raw XTC CAMERA 12M by clicking on the following image:
XTC 12M GSM INV | |
Capteur | 5 / 12 Mégapixels CMOS |
Résolution d’image | 12 M : 4000 x 3000 pixels 5 M : 2560x1920 pixels |
Résolution Vidéo | 640 x 480 à 20/IPS 320 x 240 à 20/IPS WVGA: 848 x 480 à 60/IPS |
Format vidéo | .AVI |
Format Photo | .JPG |
Écran | 2.36 pouces TFT LCD |
Sortie vidéo | NTSC |
Infrarouge | Invisible jusqu'à 10 mètres de portée |
Angle de vue | 52° F=3.1 |
Angle des capteurs PIR | 100° / 35° / 100° |
Sensibilité des capteurs PIR | 3 niveaux de sensibilité ( haut / normal / bas ) |
Distance de détection des capteurs PIR | Jusqu’à 20 m en dessous de 25°C en mode normal |
Mode d’enregistrement | Jour «couleur» et nuit «noir et blanc» |
Stockage | Carte SDHC jusqu’à 32 Go |
Temps de déclenchement | |
Nombres de prises photo | 1~3 |
Longueur des vidéos | 1~120sec. programmable |
Prise photo périodique | 1 second ~24 heures |
Photo + vidéo | Prise photo en 1er puis vidéo |
Mot de passe | 4 chiffres / digital |
Intervalle de temps | - On/Off - 1 Seconde ~ 24 Heures - Programmable |
MMS Statut | - VGA = 640x480; QVGA = 320x240;SMS; - OFF - Programmable |
MMS numéro | “0” Illimité; 0~99/jour |
MMS n° téléphone | 0 ~3 numéro de téléphone |
MMS - E-mail | 0 ~3 adresse e-mail |
Max. envoi SMS | 1~3 |
Alerte SMS “batterie faible” | oui, “Battery Low” |
Alimentation externe DC | 4.0x1.7 6 ~ 12V (1 ~ 2A) |
Auto power off | Mise hors tension automatique en 2 minutes, si aucune saisie de touche |
Autonomie | 3 ~6 mois en stand-by conso. 0.4mA |
Batterie | 4 / 8 piles LR06 AA |
Avertissement batterie faible | 4.2~4.3V |
Consommation Stand-by | 0.4 mA |
Consommation | 150mA (+350mA avec IR) |
Connexion | USB 2.0 |
Dimensions | 115 X 57 X 30 mm |
Température de fonctionnement | -30~+70°C |
Humidité de fonctionnement | 5%~95% |
Waterproof | norme IP54 |
Fixations | sangles, piédestal |
Certification | FCC & CE & ROHS |
XTC SOLAR | |
Tension de sortie | 7 Volt |
Tension de sortie maximum | 800 mA |
Puissance du panneau solaire | 0.4 W |
Batterie interne lithium polymère | 1500 mAH |
Chargement | USB |
Temps de chargement | 5 heures |
Dimension | 120 x 75 x 15 mm |
Poids | 150 g |
